JB1010ST Signal Trim Junction Box
Description
-
Transient protection using gas discharge tubes
-
Stainless steel, NEMA Type 4X enclosure
-
Section and individual cell trim capability
-
Compact enclosure only 1.75 in deep
-
Strain relief cable fitting
-
Connect two, four, six, eight or 10 single load cells (even number of load cells only)
-
Legal for Trade sealing screws, wire and seal included
Applications
-
Tank, truck and railroad scales
-
Summing 10 load cells with individual and section trimming capability
Specifically for signal trimming, the compact JB1010ST signal trim junction box with transient protection provides individual cell and section trim capability. The JB1010ST junction box totals up to ten single load cells and includes transient protection inside the element-resistant NEMA Type 4X stainless steel enclosure.
